Genie telescopic S-booms have a horizontal reach of between 9.65 meters and 24.38 meters and working heights of 14.20 meters to 40.15 meters. Compared with other aerial work platforms, telescoping booms have a much greater range of horizontal reach. Genie telescopic booms are engineered with consideration to being able to access tight areas during construction and industrial jobs. They are also known for their ability to rapidly maneuver through a job site with great drive speed and traction. The platform hydraulically turns 160�° and can stay level through the whole range. Front-entry platforms come with 227 kilogram to 272 kilogram capacity for tools and operators and are available from 1.83 meters to 2.44 meters. 360�° continuous rotating turntables offer operators quick, easy positioning.
The Z-135/70 model has a telescoping jib, called the Jib-Extend, that goes from 3.66 meters to 6.1 meters. This particular model can also reach 110�° vertically to give the user the ability to reach jobs that were previously unreachable by conventional jibs. The Z-80/60 unit's secondary reverse-articulating boom gives the user 8.83 meters of over and up reach. This feature allows up and over reaching jobs to be done with zero front arm swing.
Genie also offers the Fast Mast system which allows for precious time to be saved when both primary and secondary booms need to be lifted or for lowering the platform without having to lower the secondary boom. The Fast Mast system enables both booms to be fully raised at the same time. Both of Genie Fast Mast System's features lessens the time required for users to descend and ascend, increasing effectiveness and productivity.
